| Approx perforamce of BIEM Series, 2 pole electric monoest pump At rated volatege, 50 hz, 1 phase Ac | |||||||
| Sr no. | Model | Description | Available Pipe Size in MM | Rated Voltage | Available Voltage Range V | Max available head in Mtr. | Max Discharge LPS |
| 1 | BIEM – 1 | 0.75KW/1HP | A: 50X50 B:50X40 C:50X65 | 210 | ST: 170-240 LV: 100-220 PP: 130-440 | UP TO 32 METER | UP TO 7 LPS |
| 2 | BIEM – 1.5 | 1KW/1.5HP | A: 50X50 B:50X40 C:50X65 | 210 | ST: 170-240 LV: 100-220 PP: 130-440 | UP TO 34 METER | UP TO 9 LPS |
| 3 | BIEM – 2 | 1.1KW/2HP |
A: 50X50 B:50X40 C:50X65 D: 80X65 E: 80X80 F: 100X100 |
240 | ST: 180-240 LV: 120-220 PP: 130-440 | UP TO 34 METER | UP TO 15 LPS |
| Approx Performance OF BIEM Series, 2 pole electric monoest pump at rated voltage 50 hz, 3 phase, AC Supply | |||||||
| 4 | BIEM – 3 | 2.25Kw/3HP |
A: 80X65 B:80X80 C:100X100 D: 100X80 |
230 | ST: 170-240 PP: 220-360 | UP TO 34 METER | UP TO 20 LPS |
| 5 | BIEM – 5 | 3.75Kw/5HP |
A: 80X65 B:80X80 C:100X100 D: 100X80 |
415 | 300-400 | UP TO 38 METER | UP TO 34 LPS |
