Diesel Engine HP/RPM Model No. |
Pump Size (mm) Type |
Head (mtrs) Duty point & Range |
Discharge (Ips) At Duty Poiny & Range |
Pump Set Weight with Trolley | |
| Nett (kgs) | Gross (kgs) | ||||
| 5/2600 BI CBPS 1 | 80 x 65 GLAND | 14 12-16.5 | 11.5 17-06 | 75 | 100 |
| 5/2600 BI CBPS 2 | 100 x 100 GLAND | 8.5 7-10 | 19 14-25 | 80 | 110 |
| 5/1600 BI LPS 1 | 80 x 65 Oil Seal | 10 8.5-11 | 14 16-12 | 180 | 260 |
| 5/1500 BI PS 1 | 80 x 65 Oil Seal | 15 12.5-16 | 15 18-12.5 | 200 | 280 |
| 6.5/1500 BI PS 2 | 80x 65 Oil Seal | 15 12.5-16 | 16.5 19-13 | 200 | 280 |
| 8/1600 BI PS 3 | 80 X 65 Oil Seal | 8 6.5-8.5 | 40 48-30 | 250 | 320 |
| 10/1500 BI PS 4 | 100 X 100 Oil Seal | 16 13.5-17 | 22 32-19 | 270 | 350 |
| 12/1500 BI PS 5 | 150 X 150 Oil Seal | 12 10-13 | 45 55-40 | 365 | 455 |
| 16/1500 BI PS 7 | 150 X 150 Oil Seal | 15 12-16 | 48 56-41 | 435 | 515 |
| 14/1500 BI PS 6 | 150 X 150 Oil Seal | 15 12-16 | 48 56-41 | 370 | 450 |
| 18/1500 BI PS 8 | 150 X 150 Oil Seal | 20 17-21 | 48 58-42 | 550 | 630 |
| 20/1500 BI PS 9 | 150 X 150 Oil Seal | 25 20-26 | 50 60-43 | 555 | 645 |
